Product Description
Specification
Sensing type | Diffuse reflective |
Sensing distance | 30 cm |
Output type | PNP |
Swtich Type | L.ON / D.ON switchable |
Response time | 1 ms |
Light source | Infrared LED 940 nm (modulated) |
Operating voltage | 10~30V DC |
Current consumption | ≤20 mA |
Ambient temperature | -20℃~+55℃，No freezing |
Ambient humidity | 35%~85%RH, No condensation |
Protection circuits | Power reverse polarity protection, output reverse polarity protection, surge protection, short circuit protection |
Degree of protection | IP 65 |
Connection | 2M / 3 wires cable |
Material | PBT+Fiberglass (shell); PMMA (lens) |
Accessories | Screwdriver |
