12V Smoke Detector
Specification
| 1. Operating Voltage: DC9V~28V |
| 2. Standby Current:≤120uA@DC24V |
| 3. Alarm Current:≤15mA@DC24V |
| 4. Alarm Indicate: Red LED on |
| 5. Temperature Range: -10℃~+50℃ |
| 6. Humidity Range: 0%~95%RH (No Condensation) |
| 7. Alarm Output: Remote LED |
| 8. Sensitivity: 1.06±26%FT |
Introduction
The detectors are photo-electronic detector uses a state of-the-art optical sensing chamber. This detector is designed to provide open area protection and to be used with most conventional fire alarm
panel.
Two LEDs on each detector provide local 360° visible alarm indication. They flash every six seconds indicating that power is applied and the detector is working properly. The LEDs latch on in alarm. LEDs will be off when a trouble condition exists indicating that the detector sensitivity is outside the listed limit. The alarm can be reset only by a momentary power interruption. The detector that initiated the alarm condition will have its red LED and relays latched until reset by panel.
Showcase
| 1. Weight: 16kg |
| 2. Volume: 425mm * 260mm * 545mm |
| 3. Quantity: 100 pcs |
| 4. Can be packed according to customers" requirement |
