Multi Wired Conventional Fire Alarm Heat Detector AW-CTD805
Click on the image to view the original image
Product： views：5Multi Wired Conventional Fire Alarm Heat Detector AW-CTD805
Branch： ASENWARE
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-17 03:13
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ASENWARE
Model Number:
AW-CTD805
Model::
Conventional Fix temperature Heat Detector
Certificates::
CE Rohs ISO9001
Operating Voltage Range::
9 to 28VDC Volts
Standby Current::
40uA @ 24 VDC
Wiring Method::
2 bus system optical smoke detector
Non-polarized::
yes
Diameter::
4.0 Inch(103 mm)
Weight::
5.5 oz. (155 g)
Height::
2.2 Inch(55 mm) installed in Base
Warranty::
1 year
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard export packing including:
1) Plastic
2) Cartons
3) Pallets or plywood case for sea shipping
Port
Shenzhen
Name Conventional Fix Temperature Heat Detector
Mode No. AW-CTD805
Operating Voltage Range 9 to 28VDC Volts Non-polarized
Standby Current ≤40µA @ 24 VDC
Maximum Alarm Current ≤30mA @ 24 VDC
Operating Humidity Range  10% to 93% Relative Humidity, Non-condensing
Installation Temperature 14°F to 122°F (-10°C to50°C)
Fixed Temperature Rating 135°F (57°C)
Specific Details N/A
Size (with Base) Diameter:103mm, Height: 55mm
Weight (with Base) about 155g
