Fire Protection UV IR Flame Detector
Introduction:
- AW-CFP2166 series conventional fire alarm panel is designed based on EN54 part 2&4 standard.
- It is modularized design, the panel can extend from 1 zone to 32 zones easily.
- It has 2 level control mode by a lock
- It has 24VDC and 5VDC power supply output.
- It has FIRE and FAULT signal output.
- It has 2 general sounders output.
- Each zone has 1 circuit detectors input .
- Each zone can be disable by a button.
- It has RESET button to reset the panel.
- It has SILENCE button to stop BUZZER and SOUNDERS.
- It has EVACUATE button to start a manual fire alarm immediately.
- It has battery low protection function, when battery voltage lower than 21VDC, battery will be cut off automatically until the mains power is on.
- It has an optional GSM module for fire alarm by SMS
Parameters:
| Operating Voltage Range | 12 to 30 VDC Volts |
| Standby Current | ≤10 mA @ 24 VDC |
| Alarm Current | ≤30 mA @ 24 VDC |
| Spectrum | 180~290nm |
| Detection Angle | 110 degree |
| Detection Sensitivity with 2Kg ethanol ) | Grade I, 25m flame (Container 33cmX33cm,Height 5cm |
| Relay Contact Load | 1A,DC24V |
| Normal Status | LED blinking in 5 seconds interval |
| Alarm Status | LED lit steady |
| Protection rating | IP 32 |
| Operating Humidity Range | 10% to 93% Relative Humidity, Non-condensing |
| Operating Temperature Range | -10°C to 50°C (14°F to 122°F) |
| Height | 1.8"(45 mm) installed in Base |
| Diameter | 4.0"(103 mm) |
| Weight | 5.4 oz. (153g) |
1) ISO certified factory with 8 years professional experience and alibity to accept and
fulfill ODM/OEM orders.
Includes:
The initial design service of appearance, structure and electronic parts
Mould opening
Sampling
Semi-products testing and supply
Mass Production for formal orders
We also can quote very quickly as customer provided samples for OEM service.
2) Flexible technicals adjusting and technical support as per customer" s special request.
3) Answer your enquiries, questions and emails in 24 hours
4) Direct control on material, testing, quality, leadtime etc
