- Place of Origin:
- Guangdong, China
- Brand Name:
- Asenware
- Model Number:
- AW-CFP2166-8
- Model:
- AW-CFP2166-8
- Optional Zone:
- 1-32
- Power supply:
- 110VAC/240VAC
- Backup Battery:
- 24VDC
- Relay Output:
- NC & NO
- Warranty:
- 12 Months Free
- Sounder output:
- 2 circuits
- Fire Panel Type:
- Conventional
- OEM/ODM Service:
- Available
- Certificates:
- CE.ISO9001
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 40X20X30 cm
- Single gross weight:
- 6.0 kg
- Package Type:
- Strict & Standard Export Packing Procedures Adopted Exterior Corrugated Hardboard Carton Interior Blister Buffer Staff
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 100 >100 Est. Time(days) 7 To be negotiated
1. R&D Bsed on the EN54 part 2&4 standard. | ||||||||
2. Modularized design with extendable zones from 1 to 32 zones. | ||||||||
3. Two-level control modes by the lock. | ||||||||
4.24VDC &5VDC power supply outputs. | ||||||||
5. FIRE & FAULT signal outputs. | ||||||||
6. 2 sounders outputs. | ||||||||
7. Each zone has 1-circuit detectors' input . | ||||||||
8. Each zone can be disabled by a button. | ||||||||
9. Manua RESET available. | ||||||||
10. SILENCE button to stop all outside BUZZER & SOUNDERS. | ||||||||
11. EVACUATE button to start manual fire alarm immediately. | ||||||||
12.Batterylowlevel protection function, i.e.,lower than 21VDC, battery will be cut off automatically until the main power is on. | ||||||||
13. Optional GSM module to realize SMS notification in case of fire. | ||||||||
14. Economic, user-friendly & convenient maintenance. | ||||||||
ITEM | 1 Zone panel | 2 Zone panel | 4-8Zone panel | 12-32 Zone panel | |||
Model No. | AW-CFP2166-01 | AW-CFP2166-02 | AW-CFP2166-04-08 | AW-CFP2166-12-32 | |||
Power specification | |||||||
Mains supply voltage | 110VAC or 220VAC | ||||||
Internal power supply | 27.2VDC | ||||||
Total output current limited | 500mA @ 240VAC | 500mA @ 240VAC | 3A @ 240VAC | 3A @ 240VAC | |||
Batteries (Default Configuration) | 12V2AH*2=24VDC in Total | ||||||
End of Line device | 6.8k Ω,5% tolerance, 0.25W (colour code-blue,grey,red,gold) | ||||||
End of line resistor value | 6.8k Ω,5% tolerance, 0.25W (colour code-blue,grey,red,gold) | ||||||
Dimensions(mm) | 272*200*70mm | 320*231*90mm | 395X502X124 | 362X565X124 | |||
Weight (without batteries) | 4kg | 5kg | 7kg | 8kg | |||
Weight (with batteries) | 5.8kg | 6.8kg | 9.6kg | 12.5kg | |||
