Fire Alarm Warning Electric Bell/Electric Siren/Electric Sounder
Function of the electric fire alarm sound/ fire buzzer :
-- The fire alarm bell is automatic fire alarm and audio output device in the system.When fire happen, the fire alarm system by the output control module starts the alarm, it is ringing alarm signal to alert people to pay attention to the fire.
Working Priciple of Fire Alarm Red Steel Bell with Base110v 96dB -- When a fire occurs, smoke in the air contained in the particle concentration and the ambient temperature exceeds the standard fire alarm set value, the sensor information will be dangerous to the host, then alarm bells ringing.
Specifications of Fire Alarm Red Steel Bell with Base110v 96dB
Model No. | Diameter | Work voltage | Work current @ 24VDC | Volume(dB) |
AW-CBL2166-A-4 | 4” (100mm) | DC6V DC12V DC24V AC110V AC230V | 25 mA | 85 |
AW-CBL2166-A-6 | 6”(150mm) | 95 | ||
AW-CBL2166-A-8 | 8”(200mm) | 97 | ||
AW-CBL2166-A-10 | 10”(250mm) | 100 |
Fire Alarm Red Steel Bell with Base110v 96dB Picture
Fire AlarmRed Steel Bell with Base110v 96dB
