Advantage 2 Wire Combined Smoke & Heat Detector
Model No:AW-CSH831
Fire sensor :Photoelectric smoke chamber + Rate of rise temperature sensor
SensitivitySmoke:1.06±0.26%FT, Heat: 7.1°C/5S AIR
Control mode :Advantage software
Connection :2 wire
Operating voltage :DC9-28V
Standby current :120μA
Alarm current :<35mA
MaterialShell: Fire resistance plastic
Connector: stainless steel
Product size Diameter: 99.45 mm, height: 48.2mm
Work temperature-10℃~50℃
Work humidity95% Relative humidity, non-condensing
CustomizationLogo, color
StandardsISO9000,EN54-7, CE,SASO
Packing Details.
PackingCarton
Carton quantity10PCS/Carton, 10 Carton/Box
Carton/box sizeCarton: 20.5×23.5×11cm;
Box: 43×27×58cm
Carton/Box
weight 1.42 kg/Carton;
14.2 kg/Box
Introduction.
AW-CSH83X series combined smoke & heat detectors are combined photoelectric smoke and rate of rise temperature type, with the advantage software. The advantage software is special designed according to EN54-7 standard, very fast fire alarm speed and environment analysis function to avoid any false alarm.
AW-FD602-UV
UV Flame Detector
AW-SSD701
Independent Smoke Detector
