The company counts with the following certifications: Great Place to Work, Compulsory/Voluntary INMETRO Product Certifications and ISO 9001. Furthermore, each and every product developed and manufactured by Planeta Água is carefully tested and approved according to the NBR 16098 Norm and the Brazilian Association of Standards and Techniques (ABNT)'s specifications.
Product Description
Water Purifier FIT 230
Product with high flow, longer life and high technology. Magnificent for quality of life and health as it reduces water chlorine leaving it pure and crystal clear. Ideal for places like restaurants, coffee shops, schools, gyms and airports.
Product Variations
VARIATION | CODE |
9.3/4" with 1/2" Screw thread | 2006 |
9.3/4" with 3/4" Screw thread | 2013 |
Specification
Approximate Filter Element Life Cycle | 6000 liters (6 to 9 months) |
Approximate Purifier Life Cycle | Not established |
Flow rate | 120 liters per hour |
Particle Retention | Class C (5 to 15μm) |
With Free Chlorine Reduction | |
Product Dimensions | 305x119x119 mm |
Packing Dimensions | 314x123x123 mm |
Approximate Gross Weight | 1.84 kg |
Operation Temperature | 1 to 40 °C |
Operating Pressure | 29 to 392 kPa |
Composition | Polypropylene Body and Cover. Sealing Rubber (NBR) Metal Thread. Polypropylene Refill, MeltBlown Polypropylene and Activated Carbon. |
Included Filter Element | PA230 Refill (Code 1091) |
Color Options | White |
Application Spots | Several water use spots |
Product Paramenters
Particle Retention is measured through microns, which is a measurement used in the definition of a filter's filtering capacity regarding particle reduction. The table presented below provides examples and compares them to microns.
Microns Table
The table presents the filtering processess, the dimensions of water contaminants and their sizes in microns.
INMETRO's Classes Table
This table presents the classification of particle retention in classes A to F, according to INMETRO (Brazilian National Institute of Metrology, Quality and Technology) definitions.
Product packaging
Package Type | Quantity |
Unitary Box (image) | 1 unit per box |
Carton Box | 6 Unitary Boxes |
Pallet |
Company Profile
Global Bridge Negócios Internacionais is a Brazilian company specialized in the development of export and import business, with emphasis on market analysis, prospecting and maintenance of international business, through advisory services, consulting and commercial representation. In addition, we offer document consulting services and logistics in International Business. We work as the export department of Planeta Água.
Planeta Água
Certifications
Quality Tests
Functioning Cycle
Test of resistance to repetition, in which refills, filters and water purifiers are subjected, repeatedly, to complete functioning cycles (opening and closing). After the test, products are searched for possible non-conforming breaks or wear, allowing improvements, innovations and quality.
Tightness
Sealing test, in which the products are subjected to a constant hydrostatic pressure, for a certain period, and should not present any leak at the end of the test.
Water Hammer
Test of resistance to the phenomenon, in which are subjected to water hammer. After the test, there is a possible breakage or wear, allowing for improvements, innovations and quality.
