ADA Braille signs are no longer only found at hotels, offices, and hospitals. If your facility has a snack area, a gift shop, waiting rooms, a fitness center, mail rooms or even a room for coats, the ADA specifies that you must install a tactile Braille sign.
1. Finish and Contrast
Characters must have an eggshell, matte or non-glare finish. For easier readability, avoid signs with a shiny or gloss finish including some metal, glass and stone finishes.Characters must contrast with the background by 70%.
2. Use Grade 2 Braille
Room signs must have raised characters and use Grade 2 Braille. Tactile characters and Braille must be raised 1/32". Unlike Grade 1 Braille, Grade 2 Braille uses a series of contractions which forms a shorthand version of the text.
3. Inserts Made in the Field
4. Use Approved Fonts
characters must be in upper case and use a sans serif or a simple serif font. For room signs, the font can be no less than 5/8" high and no more than 2" high. Overhead signs require fonts that are at least 3" high.5. Use Large Pictograms
A Pictogram is optional -but, if used, the Pictogram must be at least 6" high. The equivalent verbal description must be placed directly below it, along with the accompanying Grade 2 Braille.
6. Mount Signs Correcty
Room signs should be mounted on the wall adjacent to the latch side of the door. When mounted, the centerline of a room sign should be 60" from the floor.
They do not have to use raised characters and Braille. Information such as employee names, dates, policies, directional information and schedules can be hand written or typed by the user. This part of the sign does not need to comply with ADA.
