low price export CMP 22mm illuminated metal push button switch ON/OFF/Waterproof push button switch
Model : MPO22S/F11---E
Name : 22 mm illuminated push button switch
illuminated push button switch Crust Material : 304 and 316 Stainless Steel
illuminated push button switch Thread Daimeter 22 mm
illuminated push button switch Max Rating: 5A/250VAC
illuminated push button switch Contact Resistance: less 50Mohm
illuminated push button switch Insulation Resistance: More 1000Mohm
illuminated push button switch Dielectric Intensity : 2000VAC
illuminated push button switch Operating Temp: -20 degrees Cesius---+55 degree Cesius
illuminated push button switch Mechanical Life: 1,000,000 cycles
illuminated push button switch Electrical Life: 200,000 cycles
illuminated push button switch Panel Thickness: 1---10mm
illuminated push button switch Torque: 4--15Nm
illuminated push button switch Operation Travel : about 1.8mm
illuminated push button switch IP Degree: IP67
illuminated push button switch Contact: Silver Plated Gold
illuminated push button switch Button : Stainless Steel , Copper plating
illuminated push button switch Base :PC
illuminated push button switch RohS: Made to order
illuminated push button switch Lamp Type : dot light , ring light, smybole light...
illuminated push button switch light Colors:Red ,Green,Yellow,Orange,Brown,White...
illuminated push button switch led light Voltage: 3V,6V,12V,24V,36V,48V,110V,220V AC/DC
illuminated push button switch Lamp Type: Led lamp(AC/DC)
illuminated push button switch Lamp Rated Current: about 15mA,about 2mA
illuminated push button switch Lamp Life: about 40,000 hours (Reference)
illuminated push button switch DC Led and other voltage can be made to order.
Our illuminated push button switch have achieved TUV,CE and passed SGS test.We also offer OEM and ODM service.
|
All order illuminated push button switch support online order by my aliexpress store, and payment by Escrow. Supply all products with factory price. If you are first order our products, please order some samples for trail. Follows are order process: 1. illuminated push button switch Thread diameter : We have 8mm, 12m, 16mm, 19mm, 25mm, push button switches. 2. illuminated push button switch LED/Light kinds: ring LED/light and dot LED/light 3. illuminated push button switch Switch kinds: momentary switch and latching switch 4. illuminated push button switch IP degree: IP65,IP 67,IP68... 5. illuminated push button switch Current and voltage: If you order switch with LED/light, please let me know its working Current and voltage. 6. illuminated push button switch More others products, please contact me by my email ---roycmp at 163 and dot com or skype name is roy.wu1 7. illuminated push button switch samples and smaller order as follows: (1). illuminated push button switch when you order some samples and smaller order, please contact m by email or skpye for confirming its details. (2). illuminated push button switch payment: samples and smaller order payment by pa ypal or T/T. Less 2pcs samples order, samples are free, but must pay for shipping freight. Why samples must pay shipping freight? 1. if you pay for samples, when you test samples, if you have any questions, you will contact me.If all are free, you may be won"t serious support samples testing and feedback. 2. If user buy products, they won"t pay higher cost order by internaiontal express cost.I hope our customer order many pieces and some one are wholesaler. (3). illuminated push button switch Shipping policies: Multiple Item Shipping Discount
Shipping is full price for the most expensive shipping item and 50% off the shipping price for each additional item purchased. To receive your combined shipping discount, it is very important that you do not pay for each item individually. Instead, purchase each item that you would like from us and then pay once. Your shipping will be automatically combined for you at that time. Estimated shipping time: 3-9 days (DHL,EMS,TNT,Fedex,UPS...) (4). illuminated push button switch Customer Service
(5). illuminated push button switch Privacy Policy
We do not share any customer data or information outside of the company except where necessary to ship product to you. (6). illuminated push button switch Return Policy When you receive your shipment, please inspect the packaging carefully, and note with the delivery driver any damage to the packaging at the time. If possible, take pictures and send them to us - and we will assist you in replacing your order. It is important to note, that you must notify us within 3 business days of damage from delivery.
Customer is responsible for return freight.
Of course, customer satisfaction is always our goal - so don"t hesitate to contact us! |
