4 CBM Self Loading Concrete mixer Truck Automatic Feeding Concrete mixer Truck

Click on the image to view the original image

Product：	views：44 CBM Self Loading Concrete mixer Truck Automatic Feeding Concrete mixer Truck
Size：	670X310X350 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-17 05:38

Product Details

Overview

Quick Details

Place of Origin:: Shandong, China

After-sales Service Provided:: Engineers available to service machinery overseas

Mixer Tank Volume:: 4 CBM

Pump Rotaring speed:: 10-20 r/min

Water tank capacity:: 6000L

Max.travelling speed:: 24km/h

Rated power:: 85KW

Warranty:: 1Year

Slump of concrete:: 70-260mm

Drove type:: 4*4 Wheel

Loading Bucket Capacity:: 0.55m°

Mini Steering Radius:: 4150mm

Packaging & Delivery

Selling Units:: Single item

Single package size:: 670X310X350 cm

Single gross weight:: 10000.0 kg

Package Type:: Standard Package

Lead Time:

Quantity(Set)	1 - 1	>1
Est. Time(days)	5	To be negotiated

Product Description

4 CBM Self Loading Concrete mixer Truck Automatic Feeding Concrete mixer Truck

Advantage:

1). Using hydraulic transmission device, do not rely on external force, easy to

use, continuous rotation of the tank during transport, commercial concrete
does not precipitate, not segregation.
2). Easy to operate, a handle to achieve centralized control of mixing tank,
the configuration mature and reliable, easy maintenance.
3). Low noise, no smoke, safe and reliable.
4). The use of high-intensity wear-resistant steel plate mixing tank, durable.
5). Unique inlet setting, easy to spread material.
6). Small size, transport flexibility, easy operation and maintenance, power
consumption, energy-saving effect is remarkable.
7). Blade design is reasonable, the discharge residue rate is low

4 CBM Self Loading Concrete mixer Truck
Model Type	HW40
Mixer Tank Volume	40 m³
Hydraulic Motor Model	BMSS-160
Tank Rotsry Speed	10-20 r/min
Loading Bucket Capacity	0.55 m³
Hydraulic Pump Model	CBGV-4025
Engine Rated Power	85KW
Slump of concrete	70-260mm
Max.travelling speed	24km/h
Water tank capacity	600L
Warranty	1 Year
Full Size	6.733.5m
Truck Weight	10000kg
Loading Weight	5600kg
Max Toatal Weight	15600kg
Truck Mini Steering Radius	4150mm
Tank Rotation angle	180 degree
