Indroduction of mini excavator
Mini hydraulic excavator is with compact design, and with low oil consumption, it is suitable to be used for small works, small projects, in garden, farmland, municipal works,vegetable greenhouse, digging trench It is with small engine, simple design, easy to maintain.
Features
1. Adopt double pump double valve configuration, performance improvement, compound coherent action
2.360-degree rotation, cushioning device more gentle
3.Striped rubber track climbing ability
4.Easy to use
Parameter
ITEM | UNIT | DATA | ||
BASIC PARAMETERS | Operating weight | Kg | 7500 | |
Volume of bucket | M3 | 0.28 | ||
Overall length | Mm | 6400 | ||
Overall width | Mm | 2150 | ||
Upper Structure width | Mm | 2000 | ||
Overall height | mm | 2729 | ||
Boom length | Mm | 3650 | ||
Arm length | Mm | 1850 | ||
Ground clear ance | Mm | 929 | ||
Rear-end swing radius | Mm | 1904 | ||
Min.groud clearance | Mm | 230 | ||
Tyre gauge | Mm | 1670 | ||
Wheel shaft diameter | Mm | 2400 | ||
PERFORMANCE PARAMETERS | POWE SYSTEM | Engine model | / | YD4JZG |
Modality | / | Water cooling turbocharging | ||
Bore*Stroke | Mm | f95/105 | ||
Piston displacement | L | 2.977 | ||
Power | Kw/rpm | 60/2300 | ||
Max.torque | N.n/rpm | 245/1610 | ||
HYDRAULIC SYSTEM | Hydrailic Pump | 2 | SGP1A 25F 2H9 | |
Rated flow | Ml/r | 27+27 | ||
Pilot pressure | Mpa | 3.5 | ||
Value | / | Parker | ||
Working pressure | Mpa | 20 | ||
Rated flow | L/min | 105.8 | ||
Hydraulic oil tank | L | 110 | ||
Fuel tank | L | 130 | ||
OPERATION | Swing speed | Rpm | 12 | |
Travel speed | Km/h | 35 | ||
Bucket digging force | Kn | 44 | ||
