Home > Products > 0.8 ton 1 ton 2 ton small mini micro excavator for sale
0.8 ton 1 ton 2 ton small mini micro excavator for sale
Click on the image to view the original image
Product： views：30.8 ton 1 ton 2 ton small mini micro excavator for sale
Branch： HW
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-17 05:42
  Negotiated
Product Details
Overview
Quick Details
Bucket capacity:
0.025CBM
Operating Weight:
910kg
Rated Speed:
1.5km/h
Place of Origin:
Shandong, China
Brand Name:
HW
Model Number:
HW08
Condition:
New
Moving Type:
Crawler Excavator
Maximum Digging Height:
2610mm
Maximum Digging Depth:
1650mm
Machine Weight:
910kg
Max Digging Radius:
2850mm
Certification:
ISO
Product name:
0.8 ton 1 ton 2 ton small mini micro excavator for sale
Track width:
130mm
Rated power:
8.6kw/2200rpm
displacement:
6.8ML/R
Dimensions:
2770*896*1490mm
Total length of track on land:
1230mm
Chassis ground clearance:
132mm
Max.dumping height:
1850mm
Min.rotation radius:
1330mm
Max.digging depth of bulldozer blade:
255mm
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
550 Set/Sets per Month 0.8 ton 1 ton 2 ton small mini micro excavator for sale
Packaging & Delivery
Packaging Details
1 unit ship in LCL
4-6 units load in 1x20GP container
7-12 units load in 1x40HQ container for 0.8 ton 1 ton 2 ton small mini micro excavator for sale
Port
Shanghai or qingdao port
Product Description

Product Application

This excavator is designed for small works, small projects, in garden, farmland, municipal works, vegetable greenhouse, digging trench. It is with small engine, simple design, easy to maintain
SPECIFICATION:

                                                                  0.8 ton 1 ton 2 ton small mini micro excavator for sale
Model
HW8022
size
Total transport length
4090mm
Total transport width
1200mm
Total transport height
2310mm
Minimum ground clearance
190mm
Total weight
2200kg
Ground pressure
34kpa
crawler belt
centre distance
950mm
width
230mm
Grounding length
1250mm
performance
Max digging height
3800mm
Max digging radius
4023mm
Max digging depth
2150mm
Max dumping height
2660mm
intersection angle
360°
Climbing angles
25°
traveling speed
2.5km/h
Bucket capacity
0.08m3
Bucket width
490mm
Revolute angle of movable arm(left and right)
70°/50°
Hydraulic data
Main pump
Double pump
Main pressure
160/4mpa
Maximum pump speed
2200r/min
pump displacement
25ml/r
engine
model
Changchai ZN390Q
power
20kw2200rpm
