factory price HW865-8D mini excavator for sale

Click on the image to view the original image

Product：	views：4factory price HW865-8D mini excavator for sale
Branch：	HW
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-17 05:42

Product Details

Overview

Quick Details

Bucket capacity:: 0.28CBM

Operating Weight:: 6600kg

Rated Speed:: 30km/h

Place of Origin:: Shandong, China

Brand Name:: HW

Model Number:: HW865-8D

Condition:: New

Moving Type:: Wheel Excavator

Maximum Digging Height:: 6202mm

Maximum Digging Depth:: 3228mm

Machine Weight:: 6600kgs

Max Digging Radius:: 6074mm

Certification:: ISO

Product name:: factory price HW865-8D mini excavator for sale

Min.ground clearance:: 217mm

gradeability:: 25

fuel tank:: 125L

working pressure:: 20Mpa

swing speed::: 10rpm

Total length:: 5796mm

Total width:: 2150mm

Max.torque:: 245/1610N.m/rpm

bucket digging:: 25KN

After-sales Service Provided:: Engineers available to service machinery overseas

Supply Ability

Supply Ability:: 40 Set/Sets per Month

Packaging & Delivery

Packaging Details: naked

Port: Shanghai or qingdao port

Product Description

Mini Crawler Excavator (OEM Available)

1.Using YANMAR engine, in-line four strokes, low fuel consumption, environmental protection, convenient repair and maintenance.
2.Electronic monitoring using a dot matrix type advanced multifunctional large screen liquid crystal display, electronic throttle control system has the function of throttle control, automatic idle speed, overheat protection, speed acquisition.
3.Give full consideration to reduce the working oil consumption, to obtain maximum efficiency in all kinds of work site operation.
4.Imported original hydraulic parts, quality is reliable and stable, working efficiency is high.
SPECIFICATION:

Machine weight			kg	6600
Bucket capacity			m3	028
Overall size	Bob-weight clearance ground		mm	1023
	Tail rotation radious		mm	1833
	Tail length		mm	1833
	Up height		mm	2000
	Total height		mm	2827
	Min clearance ground		mm	217
	Tires distance		mm	1670
	wheelbase		mm	2400
	Boom length		mm	3050
	Arm length		mm	1750
	Total length		mm	5796
	Total width		mm	2150
specification	engine	Model brand	/	HW865-8D
		type	/	Array,four stroke water cooling,direct injection,pressurization
		Bore*trip		95/105
		The pistion displacement	mm	2.977
		Rated power	L	48/2300
		maximum	KW/Rpm	245/1610
	Hydraulic system	Model hydraulic pump	Gear pump*2	SGPA23F2H9-L090C/R264C
		Rated displacement	m/r	23 and23
		The forerunner of pump	Mpa	3
		Main valve		8
		Pressure of work	Mpa	20
		Rated flow	L/min	105.8
		Hydraulic oil tank	L	103
		Fuel tank capacity	L	125
	Working system	Rotary speed	rpm	10
		Work speed	Km/h	0-30
		Bucket digging force	kn	25
		Arm digging force	kn	15
		Maximum traction	kn	39
		Climbing ability	°	25
		Ground pressure	Kpa	/
		Dump blade(width*height)	mm	2024/440
	Brake		/	Break air
	Brake system		/
