Overview
Quick Details
- Condition:
- New
- Type:
- exploration drilling machine
- Power Type:
- Gasoline
- Place of Origin:
- Shandong, China
- Brand Name:
- HW
- Model Number:
- HW30
- Usage:
- Coal
- Power(W):
- 28KW
- Dimension(L*W*H):
- 1524*500x300mm
- Weight:
- 280KG
- Certification:
- ISO9001
- Name:
- exploration drilling machine
- drilling depth:
- 30-50m
- Drilling diameter:
- 75mm-160mm
- Application:
- exploration drilling machine
- Spindle Speed:
- 112r/min
- Drill pipe::
- 60mm
- air compressor:
- screw 3.8m3/8
- proportional valve:
- import
- Feature:
- High Drilling Efficiency
- workpiece ratio:
- 10 holes/day
- After-sales Service Provided:
- Engineers available to service machinery overseas
- Warranty:
- 1 Year
Supply Ability
- Supply Ability:
- 300 Set/Sets per Month
Packaging & Delivery
- Packaging Details
- pneumatic mountain drilling rig is packed sturdy wooden cases
- Port
- Qingdao and Shanghai
