Earth-moving Machinery 0.8 Ton Small Wheel Loader For Sale

Click on the image to view the original image

Product：	views：3Earth-moving Machinery 0.8 Ton Small Wheel Loader For Sale
Branch：	HW
Type：	Front Loader
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-17 05:43

Product Details

Overview

Quick Details

Dimension(Long * Breadth * High):: 4540*1650*2580mm

Condition:: New

Brand Name:: HW

Place of Origin:: Shandong, China

Type:: Front Loader

Moving Type:: Wheel Loader

Rated Load:: 800kg

Certification:: CE ISO

Model Number:: HW912

Product name:: Earth-moving Machinery 0.8 Ton Small Wheel Loader For Sale

Dump height:: 2900mm

Dump distance:: 750mm

Min. turning radius(outside of bucket):: 4400mm

Operating weight:: 3000kg

Rated power/Speed:: 20KW/2300 rpm

Engine model:: L28M

Transmission type:: Full-power shift, countershaft type

Max. travel speed:: 24km/h

Bucket capacity:: 0.55m3

After-sales Service Provided:: Engineers available to service machinery overseas

Warranty:: 1 Year

Supply Ability

Supply Ability:: 7200 Set/Sets per Year

Packaging & Delivery

Packaging Details: Nude in container with triangle wood & 10mm wire
one set loading in 40HC container

Port: Qingdao or Shanghai

Product Description

Wheel loader functional properties

1.Excavation power is great ,auto lay down to save the time for working device action and improve the whole machine operation efficiency.

2.the head be designed as tiger.

Earth-moving Machinery 0.8 Ton Small Wheel Loader For Sale
Model	HW912
Rated capacity	0.55 m³
Rated load	800kg
Transportation	454016502580mm
Dump height	2900mm
Dump distance	750mm
Wheel base	2000mm
Tread	1440mm
Max. breakout force	36 KN
Total time	12s
Operating weight	3000kg
Engine
Model	L28M
Pattern	Inline, water-cooled, 4-stroke, direct injection
Rated power/Speed	24KW/2300 rpm
Torque converter and transmission system
Pattern	3-element single stage
Transmission type	Full-power shift, countershaft type
Number of gear	2 forward, 2 reverse 2
Max. travel speed	24km/h
Axle	Hualu
Main reducer pattern	Arc taper gear, model ration of first grade
Pattern of wheelside moderation	Planet gear moderation of single
Tire
Tire size	16/70-24
Steering system
Pattern	Articulated and hydraulic steering
Min. turning radius(outside of bucket)	5600mm
Max. turning angle	35°±1
Implement hydraulic system
Implement pump	CBG2063
System working pressure	16MPa
Brake system
Brake type	Air assisted oil disc on four wheel
Parking brake type	Soft axle control, outside bunch drum type

1. Executive standard: customer"s requirements. Above information serves as a reference only, we can change the parameters reasonably according to your request.
2. Optional parts: snow plow, pallet fork, gripper, rock/coal bucket, portal frame, side dump bucket, clamp bucket, light material bucket, joystick, air condition, back up camera etc.
3. Warranty: 12 months after delivery, necessary spare parts presented free. After warranty, we can always provide spare parts according to customer"s wishes.

Detailed Images
