HW
Hydraulic mountain drill rig is a series of products developed by the company with independent intellectual property rights.
Mountain drilling rig are widely used in oil drilling exploration, geological exploration, small and medium-sized mines and transportation, defense, rock Drilling and blasting hole in water Conservancy engineering, etc..
| Model | HW30 | |
| Drill depth | 50M | |
| Drilling diameter | 75-150mm | |
| Drill type | Air downthehole hammer (air hammer) | |
| Drill rod (Dia*L) | φ50*1500 | |
| Power head | Rated torque(N.m) | 800-900 |
| Rated speed range (r/Min) | 0-135 | |
| Application | Geological Exploration | |
| Rated torque | 1400N.M | |
| Max Pressure of Hydraulic System | 20Mpa | |
| Maximum hoist capacity | 15KN | |
| Stroke | 1.7M | |
| Environment temperature | ||
| Hydraulic syetem | Flow(L/Min) | 0-60 |
| Work pressure (Mpa) | 20 | |
| Main engine power (kw) | 26 | |
| Rotate Speed (r/Min) | 3600 | |
