* Excavation power is grest , auto lay down to save the time for working device action and improve the whole machine operating efficiency .
* The head be designed as tiger .
Product Parameter
Wheel Loader | |
Model | HW-912 |
Rated Capacity | 0.55m3 |
Rated Load | 800kg |
Dimension | 4540*1650*2580 |
Dump Height | 2900mm |
Dump Distance | 750mm |
Wheel Base | 2000mm |
Tread | 1440mm |
Max Breakout Force | 36KN |
Total Time | 12s |
Operating Weight | 2600kg |
Engine Model | L28M |
Pattern | Inline Water-cooled ,4-Stroke ,Direct Injection |
Rated Power /Speed | 20KW/2300 rpm |
Pattern | 3-element single stage |
Transmission Type | Full power shift |
Number of gear | 2 forward ,2 reverse |
Max travel speed | 24km/h |
Axle | Hualu |
Main Reducer Pattern | Arc taper gear ,model ration of first grade |
Pattern of wheel side moderation | Planet gear moderation of single |
Tire size | 16/70-24 |
Pattern | Articulated and hydraulic steering |
Min turning radius (outside of bucket ) | 4400mm |
Max turning angle | 35°±1 |
Implement Pump | CBG2063 |
System Working Pressure | 16Mpa |
Parking Break Time | Soft Axle Control ,Outside Bunch Drum Type |
