Product Description
- Automatic feeding
- Electronic weighing
- Self-stirring
- Walkable
- Without mixing station
- Four-wheel drive
- 1200L capacity
- Customizable and export-oriented
- We have 1200L to 2400L mixed capacity for your choose
Product Parameter
MODEL | HW-C120 Automatic feeding mixers |
Mixing system | 1200L, discharge opening height 1.8 meters |
The engine | CF4B68G-Z-13B2/CF4C100T-Z-13B2 |
The transmission way | Full hydraulic pressure drive, 4 wheel drive and two wheel steering, domestic axle
|
Walking speed | 9 km/hour at low speed, high speed 10-24 km/hour |
The cab
| Driving on the left, turn, prevent falling object type bridge, side before loading shovel |
The hydraulic system | Domestic hydraulic system, closed loop, used in hydraulic transmission and cylinder rotate |
A joystick | Four hydraulic electric joystick |
Bucket | 1200 litres, hydraulic valve |
Chute | Hydraulic adjustment point of view, to increase the length of the discharge |
Water supply system | 2 * 400 litres, hydraulic drive self-priming pump water, washing vehicles with high pressure water pump |
The brake | Expired brake brake, the double independent circuits |
Tire | Tire construction machinery tires 20.5-16 |
The power system | 24 v
|
The fuel tank | 200 litres, hydraulic tank: 200 liters |
The weight | 5000 kg
|
Overall dimensions | 5.6 meters wide, 5.6 meters high, 3.4 meters |
measurement | Electronic weighing, water meter, recipe is controlled |
