Overview
Quick Details
- Charging Capacity:
- 1.5m3
- Reclaiming capacity:
- 1.2m3
- Mixing Power:
- 55KW/2400 78KW/2400r/min
- Condition:
- New
- Place of Origin:
- Shandong, China
- Brand Name:
- HW
- Motor Power:
- 2.2kw
- Speed of Mixing Drum:
- 14r/min
- Water Supply Mode:
- Automatic
- Working Cycle Period:
- 30-40s
- Discharge Way:
- anticlockwise
- Outline Dimension:
- 6100*1850*3000mm
- Product name:
- 1.2 cubic meters Automatic feeding small concrete mixer truck
- Mixing drum blade:
- 2 and 4
- Slump of concrete:
- 70-260mm
- Pump Model:
- CBGV-4025
- Motor Model:
- BMSS-250
- water tank capacity:
- 540L
- engine model:
- CF4B68G-Z-13B2
- max.torque:
- 1500-1800N.m/r/min
- max.travelling speed:
- 24km/h
- minimum turning radius:
- 5000mm
- After-sales Service Provided:
- Engineers available to service machinery overseas
Supply Ability
- Supply Ability:
- 300 Set/Sets per Year 1.2 cubic meters Automatic feeding small concrete mixer truck
Packaging & Delivery
- Packaging Details
- 2units self loading concrete mixer/40HQ of1.2 cubic meters Automatic feeding small concrete mixer truck
- Port
- Qingdao or Shanghai port
- Lead Time:
Quantity(Sets) 1 - 2 3 - 5 >5 Est. Time(days) 30 60 To be negotiated
