Introduction of product
a.53*59 drillng rod adopted,high rigity and string delivery torque.
b. The machine is equipped with national patent technology--taper clutch,with charactristics.
c.Of string transmission troque,easy operation and free maintenance.
d.for the wich,we use large module planetary gear and add supporting frame,greatly
e.Increasing hoisting and braking ability of the winch .
f.vertical spindle are fixed by four groups of bearings to ensure that therotary machine is
g.Rigid enough for gravel layer and other comples geoloical conditions,
h.Wecan the firstone to equip mud pump with the flow 160L/min in china so that it will
i.Save cost and also make the machine compct,moblie and lightweight.
Product Paramerter
Machine Parameter | |
Drilling depth | 200m |
Max open hole caliber | 300mm |
End hole caliber | 75mm |
Drill rod caliber | 60mm |
Drillng angle | 90~75° |
Drilling weight(without power) | 975kg |
Triangle conveyer belt | B950*4 B1700*3 |
main machine moving distance | 300mm |
Power Disel engine | 22HP electric motor 15kw |
