HW-S940 new mini skid steer loader with hydraulic system

Click on the image to view the original image

Product：	views：3HW-S940 new mini skid steer loader with hydraulic system
Branch：	HW
Type：	Skid Steer Loader
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-10-17 05:47

Product Details

Overview

Quick Details

Dimension(Long * Breadth * High):: 5000*2000*3000mm

Warranty:: 1 Year

Condition:: New

Brand Name:: HW

Place of Origin:: Shandong, China

Type:: Skid Steer Loader

Moving Type:: Wheel Loader

Rated Load:: 1200kg

Certification:: CE ISO

Moving type:: wheel loader

Engine powder:: 38kw

Dump distance:: 1200mm

Wheel base:: 2600mm

Dump height:: 3600mm

Max.turning angle:: 35+_1

Capacity of load bucket:: 1.2M3

Minimum turning radius:: 4400

Engine model:: L26M

Rated speed (r/min):: 2300

After-sales Service Provided:: Engineers available to service machinery overseas

Supply Ability

Supply Ability:: 50 Set/Sets per Month skid steer loader

Packaging & Delivery

Packaging Details: Standard export package or as your requirement ,for New Mini skid steer loader

Port: Qingdao Dalian Shanghai Tianjin

Product Description

The loader machine adopts the complete machine is rationally distributed and compact; it is comfortable and convenient to handle,the turning radius is small and the cost performance is high. It is widely used in municipal administration, the construction of projects such as the building, the oil field, water conservancy,the forest farm, the military project, and so on.

It also can be used in carrying and leveling and can carry on the flexible and swift homework to scarp heap and waste residue of the large and medium-sized enterprise.

Match with high quality engine, low, low blow off of noise, driving force forceful, twist from when reserve is big. The driving force loader special use fixing an axis changes the gear speed change box, structure is compact, drive is efficient, structure stiffness is big, life-span is long.

The dyadic center equidistance hinge joint fleet of carriage, makes turn the radius is small, the expedient function is good.The drive"s cab, wide vision, air-conditioning, operation environment sealing off subtraction vibrating, allocating are comfortable, safe. Various machines and tools such as may select and use for –in-one bucket, breaking a hammer to pieces, the function are especially all in readiness.

SPECIFICATIONS FOR WHEEL LOADER
Model	HW-45G	Hydraulic pump flow(L/min)	75
Rated capacity	0.4-0.5m³	Fuel tank capacity(L)	70
Rated load	700kg	Tires	10/16.5NHS
Transporation	3350×1720×2050mm	Height at maximum extension(mm)	3980
Dump height	2380mm	Height to bucket hinge pin(mm)	3080
Dump distance	1000mm	Width with bucket(mm)	1730
Wheel base	991mm	Track width(mm)	1450
Tipping load(kg)	1400	Ground clearance(mm)	180
Max. travel speed(km/h)	12	Dump angle	30°
