Overview
Quick Details
- Charging Capacity:
- 1400L
- Reclaiming capacity:
- 1200L
- Mixing Power:
- Hydraulic Motor
- Warranty:
- 1 Year
- After-sales Service Provided:
- Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas
- Condition:
- New
- Place of Origin:
- Shandong, China
- Brand Name:
- HW
- Motor Power:
- 18.5kw
- Speed of Mixing Drum:
- 14r/min
- Water Supply Mode:
- Water Pump
- Working Cycle Period:
- 2-5min
- Discharge Way:
- Reverse-Rotation
- Outline Dimension:
- 5600* 5600*3400mm
- Actual stirring capacity::
- 1200L
- Rotary drum capacity::
- 1400L
- Engine type/displacement::
- CF4B68G-Z-13B2/CF4C100T-Z-13B2
- Rated power::
- 55kw/240078KW/2400
- Max torque::
- 255/1500-1800380/1500-1800
- Max runing speed::
- 24km/h
- Climbing capacity::
- 26 degree
- Driving way::
- 4*4
- Weight::
- 4600kg
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 610X200X300 cm
- Single gross weight:
- 5000.0 kg
- Package Type:
- in nude
- Lead Time:
Quantity(Set) 1 - 3 4 - 10 >10 Est. Time(days) 7 20 To be negotiated
