20W Waterproof IP56 marine fluorescent pendant ceiling light lamp fixture JCYA23-1 for sale
The scope of application
1. Applied to illumination of water dripping, water spattering, water coagulating place in ships, such as oven cabin, dry cabin, tunnel, pipeline and weather deck etc.
2. The environmental temperature for work is -20℃+55℃.
Products characteristic
1. The shell adopts good quality steel plate tensioned , lampshade adopts injection of PC, and has the seal structure.
2. In order to prevent from electric shocking, equipped with a copper earthing rod with the mark in the lights.
3. Plug-in type lamp holder, equipped wiring terminal inside, convenient to connect
4. The lamp has the emergency device, equipped B15d lamp holder, 24V/1SW small emergency bulb, the edge of lampshade marks the marking.
5. Equipped compensating capacitance inside the lamp, also has the good effect of start.
Adopt standard
Conform to JISF8008 2002 standard and GRADE ENTRY NORMS FOR STEEL SHIPS.
Production authentication
Approval by CCS(China Classification Society), certificate number 00515Q20619ROM.
Specifications
| Type | Power | Voltage | Compensating capacitance | Power factor | Lamp holder | Cable outside | Protection class | Weight |
| JCYA23-1 | 1×20W | 110V/60Hz 220V/50Hz | 4.75µf | >0.85 | G13 | Φ12-Φ16 | IP56 | 4kg |
| JCYA23-2E | 2×20W | 7.5µf | ||||||
| JCYA43-1 | 1×40W | 7.5µf | 7kg | |||||
| JCYA43-2E | 2×40W | 7.5µf |
1. Marine Lighting: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine Deck Equipments: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine Deck Mooring: Anchor, Anchor Chain.
4. Marine Life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.
I. Packaging
1.Wooden Case; 2.Iron Frame; 3.According to customers" request;
II. Shipping
By Express/ Air/ Sea/ Train.
Q1: Why we choose you?
11 professional engineers can provide overall solution services.
13 years specialising in marine deck equipment .
18 long-term cooperation supporting factories.
24 hours a day after-sale technical support .
Q2: What kind of payments do you accept?
T/T, L/C, Western Union, D/A, D/P, MoneyGram, Paypal etc..
Q3: How about the Delivery Time?
We could finish the production within 30 days
Q4: What"s the MOQ?
MOQ is 1 set.
