- Place of Origin:
- Chongqing, China
- Brand Name:
- JUVI
- Model Number:
- JVH-014
- Power Source:
- Electric
- Application:
- Boat
- Product name:
- 12V 1600WElectrical Boat anchor Horizontal Windlass
- Max Pressure(bar):
- 1600W
- Max. Pull (kg):
- 1400
- Max. Load (kg):
- 660
- Power supply:
- 12V/24V
- Rope Size:
- 20-24mm
- Weight:
- 26kg
- No Load Absorption:
- 90A
- Line speed:
- 20m/min
- Chain size:
- 10-12mm
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 45.5X45X25.5 cm
- Single gross weight:
- 34.0 kg
- Package Type:
- Netural packing
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 50 >50 Est. Time(days) 7 To be negotiated
112V 1600W Electrical Boat anchor Horizontal Windlass
| Model | Net Weight (kg) | Power Supply | Motor | No Load Absorption | Max. Load (kg) | Max. Pull (kg) | Line Speed | Rope Size | Chain Size |
| SH400 | 13.5 | 12V/24V | 600W | 600 | 22m/min | 6/7mm | |||
| SH1000 | 18 | 1000W | 750 | 25m/min | 8mm | ||||
| JVH-011 | 16 | 12V/24V | 600W | 50A | 190 | 600 | 30m/min | 12-14mm | 6-7mm |
| JVH-012 | 25.5 | 1000W | 90A | 350 | 750 | 25m/min | 14-16mm | 8-10mm | |
| JVH-013 | 32 | 1400W | 125A | 520 | 1100 | 25m/min | 18-20mm | ||
| JVH-014 | 34 | 1600W | 140A | 660 | 1400 | 20m/min | 20-24mm | 10-12mm | |
| JVH-015 | 36 | 220V/380V | 2000W | 6A | 900 | 2000 | 10-13mm | ||
| JVH-016 | 38 | 3000W | 9A | 1200 | 2500 | 10-13mm | |||
| EB2000 | 8.5 | 12V/24V | 6 feet/min | ||||||
| EB3000 | 11 | ||||||||
| GB001H | 160 | 2200W | 190 | 600 | 30m/min | 12.5mm | |||
| GB002H | 260 | 3500W | 350 | 750 | 25m/min | 14mm | |||
| GB003H | 320 | 4000W | 520 | 1100 | 16mm | ||||
| GB004H | 410 | 5000W | 660 | 1400 | 20m/min | 17.5mm | |||
| GB005H | 490 | 6000W | 900 | 2000 | 19mm | ||||
| GB006H | 530 | 7500W | 1200 | 2500 | 20.5mm |
Features:
1.Twin capstan, single gypsy, but you also can choose twin gypsy.
2.Reversible motor.
3.Independent operation of capstans and gypsy by declutching the drive.
4.Simple deck mounted installation with no under deck parts.
5.Simplified maintenance with ability to strip the running gear (chain-wheel and drum) from the windlass without disturbing the windlass mounting.
6.Totally sealed gearbox with ground worm drive.
7.Horizontal windlass casing are cast marine grade aluminium alloy with white epoxy enamel finish.
8.Fit include hand-switch,foot switch,manual handle,solenoid.
1. Marine ship yacht boat light: Navigation signal light, Incandescent light, Fluorescent light, Searchlight, Explosion-proof light etc.
2. Marine deck: Winch, Windlass, Capstan (AC, DC, Vertical, Horizontal, Electric, Hydraulic etc.)
3. Marine deck mooring: Anchor, Anchor chain.
4. Marine life-saving: Rescue boat, Life Jacket, Buoy etc.
5. Customized products according to customers" request.
