The scope of application: It can be used safety and reliably in the place with explosive air mixture, with explosive material ⅡA, ⅡB, The temperature group is T1-T4 in cabin and outdoor place.
Products characteristic:
1. The shell is made of good quality brass foundry, toughened glass lampshade.with brass guard.
2. The gland has two kind, one is tube screw type, screw is G3/4, Another one is bugle-type.
Adopt standard: Conform to National standard GB3836, GB12045 THE TECHNICAL CONDITION OF MARINE EXPLOSION-PROOF LIGHT.
Production authentication:
1. Passed the examination of National Explosion-proof Safety Supervisal and Inspection station for Luminaire.
2. Approval by CCS(China Classification Society), certificate number 00515Q20619ROM.
Specification:
|
| Power | Voltage | Weight | Material | Protection class | Lamp | Illuminant | Cable outside Diameter | Explosion-proof mark |
ingandescent explosion-proof light | CFD2a | 200W | 220V | 19kg | Brass | IP55 | E27 | Incandescent | 11 ~ 13 | Exd IIBT3 |
CFD2b | 125W | 220V | 19kg | Self-ballast high-pressure mercury lamp | Exd IIBT3 | |||||
CFD3 | 25W | 24V | 13.5kg | IP56 | Incandescent | Exd IIBT4 | ||||
40W/60W | 110V | |||||||||
40W/60W /100W | 220V | |||||||||
CFD3- I | 25W | 24V | 8.5kg | Exd IICT4 | ||||||
40W/60W | 110V | |||||||||
40W/60W /100W | 220V |
| Packaging Detail | Label + Inner Box + Export Carton |
| Common Packing | Label,Color Inner Box,etc |
| Delivery | By Courier,By Air,By Sea |
| Port | Ningbo,Shanghai,Guangzhou |
ChongQing Juvi Marine Equipment Co.,Ltd, can supply wide range of marine equipment for shipbuilding,ship repairing, ocean engineering and offshore projects etc.
Our main products include:
1, Marine life-saving and fire-fighting equipment: Lifeboat and davit,liferaft,lifejaket and lifebuoy etc.
2, Marine deck machineries: Anchor electic winch,Mooring Winch, Capstan,Steering gear etc
3, Marine deck mooring fittings: Anchor, Anchor chain, Panama chock, Roller fairlead,Bollard,Chain stopper etc.
4, Marine power and propulsion equpment: Rudder system,Shaft system, Propeller,Rudder propeller,Bow thruster,Emergecy generator set etc.
5, Marine cabin machinery: Marine pump, Ventilation fan,Boiler,Incinerator,Oily water separator, Hydrophone tank, Sewage treatment unit, Galley and laundry equipment etc.
6, Marine outfitting: Marine door,window,side scuttle,small hatch cover,manhole cover, accommodation ladder,gangway ladder,wharf ladder, marine sacrifical anode,pipes and fittings etc
6, Rubber product: Rubber fender, Pneumatic(Yokohama) fender, rubber packing/rubber seal for hatch cover, air bag for ship grading, rubber air pontoon
7, Boat and yacht hardward: Stainless steel anchor, anchor chain,bollard, chock,fairlead, wheel,ladder,shackle,thimble,hook etc.
8, Other industrial product: Elevator balance compensating chain, air filter, Panel filter,Bag/Pocket filter, HEPA/ULPA air filter etc.
