The scope of application: Applied to illumination of water dripping, water spattering, water coagulating place in ships, such as oven cabin, dry cabin, tunnel, pipeline and weather deck etc..
Products characteristic:
1. The shell adopts good quality steel plate tensioned, lampshade adopts injection of PC, and has the seal structure.
2. In order to prevent from electric shocking, equipped with a copper earthing rod with the mark 8 in the lights.
3. Plug-in type lamp holder, equipped wiring terminal inside, convenient to connect.
4. The lamp equipped B15d lamp holder, used for 24V/15W emergency bulb, the edge of lampshade marks the marking,remark clear that need the emergency device when order.
5. Equipped compensating capacitance inside the lamp, also has the good effect of start.
Adopt standard: Conform to CB/T 3857-1999 standard.
Production authentication: Approval by CCS(China Classification Society), certificate number 00515Q20619ROM.
Specification:
|
| Power | Voltage | Power factor | Cable outside diameter | Protection class | Weight | Material | L | L1 | H | Lamp holder |
JCY23-2 | Fluorescent pendant light | 2×20W | 110V/60Hz 220V/50Hz 220V/60Hz | >0.85 | 12~16 | IP56 | 5.35kg |
| 692 | 480 | 134 | G13 |
JCY23-2E | 5.35kg | With emergency | 134 | |||||||||
JCY23-2EF | 5.5kg | With emergency and guard | 155 | |||||||||
JCY33-2 | 2×30W | 9.0kg |
| 992 | 700 | 134 | ||||||
JCY33-2E | 9.0kg | With emergency | 134 | |||||||||
JCY33-2EF | 9.0kg | With emergency and guard | 155 | |||||||||
JCY43-2 | 2×40W | 8.95kg |
| 1299 | 134 | |||||||
JCY43-2E | 8.95kg | With emergency | 134 | |||||||||
JCY43-2EF | 8.95kg | With emergency and guard | 155 |
| Packaging Detail | Label + Inner Box + Export Carton |
| Common Packing | Label,Color Inner Box,etc |
| Delivery | By Courier,By Air,By Sea |
| Port | Ningbo,Shanghai,Guangzhou |
