| Slit Lamp Microscope | ||
| Art.No. | SLM-6A | |
| Microscope | Microscope Type | Galilean stereoscopic microscope |
| Magnification selection | 5 steps by drum rotation | |
| Eyepiece | 12.5x | |
| Magnification Ratio | 6×(dia33mm),10×(dia22.5),16×(dia14.1mm),25×(dia8.8mm),40×(dia5.5mm)/BL-6AT( 10X, 16X ,25X ) | |
| (Field of view ) | ||
| PD adjustment | 50mm ~ 82mm | |
| Diopter Adjustment | +7D ~ -7D | |
| Base | Side Shift:110mm Depth Shift :90mm Height Shift :30mm | |
| Chin rest | Height Shift:80mm Fixation Target:red LED | |
| Illumination System | Slit width | 0 ~ 14mm continuous (at 14mm,slit becomes a circle) |
| Slit height | 1 ~ 14mm continuous | |
| Slit angle | 0 ~ 1800 continuous dia14mm ,dia10mm, dia5mm , dia3mm , | |
| Light spot diameter | dia14mm ,dia10mm, dia5mm , dia3mm ,dia2mm ,dia1mm ,dia0.2mm ,dia1mm~dia1-14mm continuous | |
| Filter | Heat absorption ,Grey ,Red-Free ,Cobalt Blue | |
| Illumination bulb | 12V 50W halogen lamp | |
