| Model NO. | DS261 |
| Wavelength | 340~810nm |
| Absorbance Resolution | 0.0001A |
| Absorbance Accuracy | ±0.0003A(0~2.5A) |
| Repeatability (CV %) | ≤2% |
| Operation | Random access,Direct reading system |
| Method | End point, Kinetic, Fixed time, Immunoturbidimetric,1-2 reagent, Multistandard, reagent/serum blank,etc. |
| Assay Item | 40 assay items+3 ISE items(optional) |
| Throughput | 1 Reagent:257 tests/h (max) 2 Reagent:150 tests/h With ISE:+120tests/h |
| Sample Position | 60 positions Including standard, control and stat; either serum cup or primary tube available |
| Sample Volume | 1~100ul,0.1ul / step |
| Reagent Position | 40 positions,or 80 positions(optional) |
| Reagent Volume | R1:1~400ul,1ul / step,R2:1~400ul,1ul / step |
| Reagent / Sample Probe | With liquid level sensor, collision sensor, teflon coating and automatic washing |
| Cuvette | High quality uv-transmitted plastic cuvette or quartz glass cuvettes on request |
| Washing | 8 channels automatic washing system for reaction cuvettes, Independent washing station for each sample/reagent probe and mixer |
| Calibration | Linear, Non-linear, Multi point, K factor |
| Sample Dilution/Retest | Sample can be diluted and retested if results are out of range or sample is insufficient |
| Light Source | Halogen lamp |
Usual package,paper box with foam to keep fixed.
If you have other requirement , we can do as you want,such as wooden box .
Below pictures are just sample as reference.
1. 24-hour service
2.100% QC inspection before shipment.
3.Warranty: 12 months free after-sale service for customers, and be responsible
