AC 240V DC 28V 14 Pins 4NO4NC Ormon 12V 220V Relay HH54P/MY4 Micro Power Relay 3A
Click on the image to view the original image
Product： views：5AC 240V DC 28V 14 Pins 4NO4NC Ormon 12V 220V Relay HH54P/MY4 Micro Power Relay 3A
Branch： Daier
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 20:12
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Daier
Model Number:
HH54P(MY4)
Theory:
Electromagnetic Relay
Usage:
General Purpose
Size:
Miniature
Protect Feature:
Sealed
Contact Load:
Low Power
Item:
HH52P(MY2)
Rating:
3A
Voltage:
240VAC/28VDC
Coil Rating:
6V-250V
LED Color:
RED
Terminal:
14PIN Solder terminal
Circuit:
4NO4NC
Popular Used Voltage:
6VDC/12VDC / 24VDC/ 220 VAC
Operating Temperature:
-25℃~+75℃
Electrical Life:
≥10000 Cycles

Packaging & Delivery

Selling Units:
Multiple of
Package size per batch:
25X15X7 cm
Gross weight per batch:
1.5 kg
Package Type:
20pcs/box,AC 240V DC 28V 14 Pins 4NO4NC Ormon 12V 220V Relay HH54P/MY4 Micro Power Relay 3A
Lead Time:
Quantity(Piece)1 - 400>400
Est. Time(days)10To be negotiated
Product Description
Item
AC 240V DC 28V 14 Pins 4NO4NC Ormon 12V 220V Relay HH54P/MY4 Micro Power Relay 3A
Rating
3A 240VAC /28VDC
Circuit
4NO4NC
Housing Color
Black
Contact Resistance
≦30MΩ
Dielectric Resistance
1500VAC 1 Minute
Insulation Resistance
≧100MΩ
Important:
The Price is not include the socket, if you need the socket, pls check the related product for purchase, pls note!!!
Electrical life
>10000 Cycles

Electromagnetic RELAY & RELAY SOCKET:


It has applied to all kinds of equipment, it is remote control, testing, communication, automatic control, electromechanical integration door control industry relay.


Its main functions are simultaneous switching, interrupting, switching on parallel circuits and controlling large currents with small control variables. It can form control circuits to realize automatic operation..
