Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- L12F-10N
- Protection Level:
- IP67
- Max. Current:
- 2A
- Max. Voltage:
- 250VAC
- Item number:
- Small Round Push Button Switch
- Function:
- Momentary Or Latching
- Led color:
- Red Yellow White Blue Green
- Contact Resistance:
- 50 mΩ max
- Operating Force:
- 3-6N
- Dielectric Strength:
- >2000VAC 1Min
- Electric life:
- 100,000 cycles
- Operating Temperature:
- -25°C ~+55°C
- Material:
- Plastic
- IP Class:
- IP67
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 21X14X6 cm
- Gross weight per batch:
- 1.1 kg
- Package Type:
- 12MM Plastic Flat Button 4Pin Momentary Or Latching Illuminated Waterproof Small Round Push Button Switch is 40pcs/box
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 50000 >50000 Est. Time(days) 7 To be negotiated
Product Description
Push button switch is one of the most easy and quick to operate.The Switches, buttons are more attractive in appearance and the material that are used illuminative its surface, labeled as graphic convenience, operating the switch lead to the user satisfaction, can also be used in SMART CAP system where one can input device products, this is definitely the best choice for designers. Pls check the datasheet below:
