Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- A16-10SR-F
- Protection Level:
- IP40
- Max. Current:
- 3A
- Max. Voltage:
- 250VAC
- Item number:
- 16MM Emergency Stop Button
- ContactConfiguration:
- SPST
- Body Color:
- Yellow
- Button Color:
- Red
- Button Shape:
- Flat
- Insulation Resistance:
- DC 500V100MΩ Min
- Dielectric Strength:
- 2000VAC for 1 Min
- Electric Life:
- 10,000 cycles Min
- Operation Temperature:
- -25°C~+55°C
- IP Class:
- IP40
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 20X20X10 cm
- Gross weight per batch:
- 0.5 kg
- Package Type:
- Flat Button SPST 16MM Emergency Stop Button is 40pcs/box.
- Lead Time:
Quantity(Piece) 1 - 400 >400 Est. Time(days) 7 To be negotiated
