Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- DS-501
- Protection Level:
- IP40
- Max. Current:
- 1A
- Max. Voltage:
- 250VAC
- Item number:
- Normally Closed Push Button Switch 14MM
- Function:
- Momentary
- Body Color:
- Black
- Button Color:
- Red, Green
- Insulation Resistance:
- DC 500V100MΩ Min
- Contact Resistance:
- 50mΩ Max
- Dielectric Strength:
- 1500VAC for 1 Min
- Electric Life:
- 10,000 cycles Min
- Operation Temperature:
- -25°C~+85°C
- IP Class:
- IP40
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 22X13X6 cm
- Gross weight per batch:
- 1.0 kg
- Package Type:
- 250VAC 2PIN Soldering Type SPST Latching 16MM Push Switch Button is 200pcs/bag.
- Lead Time:
Quantity(Piece) 1 - 200000 >200000 Est. Time(days) 7 To be negotiated
