Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- PBS-128
- Protection Level:
- IP40
- Max. Current:
- 1A
- Max. Voltage:
- 30VDC
- Item number:
- Plastic Flashlight Button Switch
- Body Color:
- White
- Function:
- ON OFFFlashlight Button Switch
- Material:
- Plastic
- Operational Temperature:
- -25°C ~ +70°C
- Contact Resistance:
- 100 mΩ max
- Insulation Resistance:
- ≥100MΩ
- Dielectric Strength:
- AC 500V 1Minute
- Electric life:
- >10,000 cycles
- Operating Force:
- 300gf±100gf/ 700gf+100gf
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 20X20X10 cm
- Gross weight per batch:
- 0.9 kg
- Package Type:
- PBS-128Flashlight Push Button Switch is 1000pcs/bag
- Lead Time:
Quantity(Piece) 1 - 1000000 >1000000 Est. Time(days) 7 To be negotiated
