Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- PBS-13B
- Protection Level:
- IP40
- Max. Current:
- 4A
- Max. Voltage:
- 250VAC
- Item number:
- Momentary Push Push Button
- Function:
- Momentary
- Button color:
- Red, Green
- Insulation Resistance:
- DC 500V100MΩ Min
- Contact Resistance:
- 20mΩ Max
- Dielectric Strength:
- 1000VAC for 1 Min
- Electric life:
- 50,000 cycles Min
- Operation Temperature:
- -25°C~+85°C
- IP Class:
- IP40
- Terminal Type:
- Screw Type
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 20X20X10 cm
- Gross weight per batch:
- 2.0 kg
- Package Type:
- 2Pin Screw Terminal 250VAC Momentary Push Push Button is 100pcs/bag.
- Lead Time:
Quantity(Piece) 1 - 100000 >100000 Est. Time(days) 7 To be negotiated
