Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- GQ22F-11EL
- Protection Level:
- IP67
- Max. Current:
- 5A
- Max. Voltage:
- 250VAC
- Item number:
- 22mm SPST 1NO 1NO Anti-Vandal Push Button Switch
- Electric life:
- 50,000 cycles
- Contact Resistance:
- 50 mΩ max
- Insulation Resistance:
- 500V DC1000MΩ Min
- Dielectric Strength:
- 2000VAC
- Operating Temperature:
- -20°C ~+55°C
- Function:
- SPDT 1NO+1NC
- Operational Force:
- 5N Max
- Material:
- Stainless Steel
- Led Lamp Color:
- Red/Green/Blue/White/Yellow/Orange
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 20X10X6 cm
- Gross weight per batch:
- 1.0 kg
- Package Type:
- GQ22F-11ELAnti-Vandal Push Button Switch is 20pcs/box
- Picture Example:
- Lead Time:
Quantity(Piece) 1 - 400 >400 Est. Time(days) 7 To be negotiated
