Home > Products > 3.2X4.2mm TST3425 White Rubber Tactile Switch with 4 SMT Terminals
3.2X4.2mm TST3425 White Rubber Tactile Switch with 4 SMT Terminals
Click on the image to view the original image
Product： views：33.2X4.2mm TST3425 White Rubber Tactile Switch with 4 SMT Terminals
Branch： Daier
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-11-19 20:14
  Negotiated
Product Details
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Daier
Model Number:
TST3425
Protection Level:
IP40
Max. Current:
50mA
Max. Voltage:
12VDC
Rated Current:
50mA
Rated Voltage:
12VDC
Type of Actuation:
Tactile feedback
Button Color:
White
Base Color:
White
Size:
3.5x7x3.5MM
Free sample:
Available
OEM&ODM:
Yes
Packing:
Carton box
Operating Temperature:
-30~+85℃

Packaging & Delivery

Selling Units:
Multiple of
Package size per batch:
25X18X7 cm
Gross weight per batch:
1.0 kg
Package Type:
1000pcs a box of 3.2X4.2mm TST3425 White Rubber Tactile Switch with 4 SMT Terminals
Lead Time:
Quantity(Piece)1 - 1000000>1000000
Est. Time(days)7To be negotiated
Product Description
Product Name
3.2X4.2mm TST3425 White Rubber Tactile Switch with 4 SMT Terminals
Rating
50mA 12VDC
Funtion
OFF-(ON) Momentary
Button Color
White 3.2X4.2mm TST3425 White Rubber Tactile Switch with 4 SMT Terminals
Electonical Life
100,000 Cycles
Environment temperature
 T-30 - T85
Min Insulation Resistance
100mΩ
Products Show

TST3425 Small Tactile Switch:

TST3425 is an on/off electronic small tactile switch that is only on when the button is pressed or if there is a definitive change in pressure.
It was used for circuit board, the height for the switch is 2.5mm.
The Tactile Switch applications include: Low power, miniature devices, digital switching, anything where operator feedback is required (a switch confirmation coming from the switch being depressed) will find that the perfect choice is a Tactile switch.
