16mm Momentary Flat Touch Push Button Piezo Igniter Power Switch

Click on the image to view the original image

Product：	views：316mm Momentary Flat Touch Push Button Piezo Igniter Power Switch
Branch：	Daier
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 20:14

Product Details

Overview

Quick Details

Package Type:: 20PCS/BOX for 16mm Momentary Flat Touch Push Button Piezo Igniter Power Switch

Lead Time:

Quantity(Piece)	1 - 2000	>2000
Est. Time(days)	7	To be negotiated

Product Description

Model	PZ16F-10
Operation Type	Momentary
Crust Material	metal/Aluminum
Degree of Protection	IP67
Maximum Voltage	250VAC
Thermal Current	2A
Minimum Applicable Load	5V AC/DC,1mA
Contact Material	Silver Plated
Terminal Style	.110" Solder/Quick Connect
Operating Temperature	-25°C ~+55°C
Operating Humidity	45%~85% RH
Contact Resistance	50mΩ max.
Insulation Resistance	100mΩmin. (500V DC megger )
Vibration Resistance	10~55HZ, amplitude 1.2mm p-p
Degree of Protection	>10g
Electrical Life	100,000 operations min. (at full rated load)
Mechanical Life	Maintained:1,000,000 operations min. Momentary:1,000,000 operations min.
Dielectrical Life	Switch Unit: 2,000VAC,1 minute between terminals of same pole; 1,000VAC,1minute between contact and lamp terminals. Illumination Unit:2,000VAC,1min. Between live part/ground
Soldering Temperature	20W/5 seconds or 260 °C/3 seconds

Product Show

Related Roducts

PZ16-10-R

PZ19-10-A

PZ22-10-S
