- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- STS-101
- Protection Level:
- IP40
- Max. Current:
- 1.5A
- Max. Voltage:
- 250VAC
- Item number:
- 6mmPlastci BlackButton SPST Momentary Pushbutton Switch
- Body Color:
- Black
- Function:
- Momentary
- Material:
- Plastic
- Operational Force:
- 90±15gf
- Contact Resistance:
- 100 mΩ max
- Insulation Resistance:
- ≥100MΩ
- Dielectric Strength:
- 500V AC for 1 min
- Electric life:
- ≥20,000 cycles
- approved:
- CQC. Rohs. CE
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 20X10X5 cm
- Single gross weight:
- 0.5 kg
- Package Type:
- STS-101 6mm Panel Mounted Plastci BlackButton SPST Momentary Pushbutton Switch is 100pcs/bag.
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 1000 >1000 Est. Time(days) 10 To be negotiated
DS-211
Specifications:
1. Rating: 1.5A 250VAC
2. Function: Momentary
3.Contact Resistance: 100mΩ max
4. Insulation Resistance:100MΩ min
5. Dielectric Strength:500V AC for 1 min
6. Operating Force: 90±15gf
7. Electrical Life: ≥20,000 Cycles
Push button switch is one of the most easy and quick to operate.
The Switches, buttons are more attractive in appearance and the material that are used illuminative its surface, labeled as graphic convenience, operating the switch lead to the user satisfaction, can also be used in SMART CAP system where one can input device products, this is definitely the best choice for designers
