Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- GQ-8HJ
- Protection Level:
- IP65
- Max. Current:
- 1A
- Max. Voltage:
- 24VDC
- Item number:
- 8mm Switch
- Contact Rating:
- 1A 24vdc
- Electric life:
- 10,000 cycles
- Contact Resistance:
- 50 mΩ max
- Insulation Resistance:
- >100Ω 500VDC
- Dielectric Strength:
- >1000VAC 1Min
- Operational Temperature:
- -20°C~ +85°C
- Function:
- SPST
- IP Class:
- IP65
- Operating Force:
- 2-3N Max
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 21X14X6 cm
- Gross weight per batch:
- 1.1 kg
- Package Type:
- High Button 2Pin Soldering Terminal Metal Momentary 8mm Switch is 50pcs/box.
- Lead Time:
Quantity(Piece) 1 - 50000 >50000 Est. Time(days) 10 To be negotiated
