Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- GQ40F-22EM
- Protection Level:
- IP67
- Max. Current:
- 5A
- Max. Voltage:
- 250VAC
- Product type:
- Double Pole Double Throw Switch
- LED color:
- Red Yellow Green White Blue
- Electrical life:
- 50,000 cycles
- Contact resistance:
- 50m-ohms max
- Insulation resistance:
- 1,000M-ohms min @ 500VDC
- Dieiectric strength:
- 2,000V RMS 50~60Hz
- Operating temperature:
- -20~+55°C
- Function:
- Momentary
- Protection level:
- IP67
- Operating force:
- 5.5-7N max
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 21X14X6 cm
- Gross weight per batch:
- 1.5 kg
- Package Type:
- 40MM Momentary Flat Button Ring Illuminated Waterproof Metal Double Pole Double Throw Switch is 20pcs/ box.
- Lead Time:
Quantity(Piece) 1 - 20000 >20000 Est. Time(days) 10 To be negotiated
