Overview
Quick Details
- Place of Origin:
- Zhejiang, China
- Brand Name:
- DAIER
- Model Number:
- GQ-10H-10E
- Protection Level:
- IP67
- Max. Current:
- 2A
- Max. Voltage:
- 250VAC
- Item number:
- 10MM Switch
- Contact Rating:
- 2A 250VAC
- Electric life:
- 10,000 cycles
- Contact Resistance:
- 50 mΩ max
- Insulation Resistance:
- >100Ω 500VDC
- Dielectric Strength:
- >2000VAC 1Min
- Operational Temperature:
- -25°C ~ +55°C
- Function:
- SPST
- IP Class:
- IP67
- Operating Force:
- 3-6N Max
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 21X14X6 cm
- Gross weight per batch:
- 1.1 kg
- Package Type:
- High Round Button Soldering terminal Latching Or Momentary 4Pin SPST Metal Ring Illuminated 10MM Switch is 50pcs/box.
- Lead Time:
Quantity(Piece) 1 - 50000 >50000 Est. Time(days) 10 To be negotiated
