LED lighting source, green and energy saving;
IP65, available for outdoor use;
Polycarbonate(PC) diffuser;
3 Hours emergency(option available);
Anti-glare design: against from the dizzy light;
No UV, no infrared, no other Hazardous Substances;
No noise, no flicker, resistance from vibration;
CE&ROHS compliant;.
Two years warranty;
Electrical parameters:
Input voltage: ( 50/60Hz) AC 100-240V
Power consumption: 8W (6-12W available)
PF: >0.9
LED Driver output voltage: DC 36V
LED Driver output current: 300mA ±15mA
Light source: Epistar 3528SMD LED 160 PCS
Color Temperature: 3000K /4000K /6000K (optional)
CRI: >75
Flux luminous: 960Lm for standard version
880Lm for emergency version
Luminous efficacy: 120Lm /W for GL0804CA
110Lm /W for GL0804EA
View angle: 120°
Housing material: Die-cast aluminum base , PC diffuser
IP Rating: IP 65
Life Span: Up to 50,000 hours
Operation temperature: -20 deg C to 40 deg C
Dimension: 390*110*90mm
Package: 420*120*115mm
Net Weight: 2.2KG(approx)
Emergency:
Type: Maintained
Battery(High-Temperature): 9.6V 1.6AH Ni-MH rechargeable
Emergency output: 30% nominal power
Emergency duration: >3 Hours
Charge time: < 12Hours
LED indication: Red: charging;
Green: fully charged;
Yellow: battery fault or disconnected
Test button: AC power on: Push and hold the button to enter emergency mode;
release button to come back AC power mode
