LED lighting source, green and energy saving;
IP65, available for outdoor use;;
Die-cast aluminum body and PC diffuser;;
3 Hours emergency(option available);
Microwave/ Motion sensor;
Automatic dims when detected area is unattended
--Adjustable range (1-8m)
c/w M20 x 1.5 IP65 Gland
Anti-glare design: against from the dizzy light;
No UV, no infrared, no other Hazardous Substances;
No noise, no flicker, resistance from vibration;
CE&ROHS compliant;
Five years warranty;
Electrical parameters:
Input voltage:(50/60Hz) AC 100-240V
Power consumption: 20 W (24.5W for emergency versions)
Power factor(PF): >0.9
LED Driver output voltage: DC 36V
LED Driver output current: 500mA ±25mA
Light source: SMD LED
Color Temperature: 3000K /4000K 6000K (optional)
CRI: RA>75
Flux luminous: 2200- 2400Lm
Luminous efficacy: 120Lm /W for GL2002CA
120Lm /W for GL2002SA
110Lm W for GL2002EA
110Lm /W for GL2002ESA
View angle: 100°
Housing material: Die-cast aluminum base , PC diffuser
IP Rating: IP65
Life Span: Up to 50, 000 hours
Operation temperature: -20degC to 40degC
Dimension: 315 *98mm
Package: 330*330*110mm
Net Weight: 3.8KG(approx)
Emergency:
Type: Maintained
Battery(High-Temperature): 9.6V 3.2AH Ni-MH rechargeable
Emergency output: 30% nominal power
Emergency duration: >3 Hours
Charge time: < 12Hours
LED indication: Red: charging;
Green: fully charged;
Yellow: battery fault or disconnected
Test button AC power on: Push and hold the button to enter
emergency mode; release button to come back AC power mode
Microwave Sensor:
Sensor range: 180 degree; 0.5 - 8M(adjustable)
Sensing interval: 10s to 5min max (adjustable)
Sensing interval output: 25% nominal power
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than .
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
