This instrument complies with IEC 61010-1, CAT. III 1000V and CAT. 600V overvoltage standards. See Specifications.
To get the best service from this instrument, read carefully this user"s manual and respect the detailed safety precautions.
DC Voltage
400mV/4V/40V/400V (0.5%+2)
1000V (0.8%+2)
AC Voltage
400mV (2.0%+3)
4V/40V/400V (0.8%+3)
750V (1.0%+3)
DC Current
400A/4000uA/40mA/400mA (0.8%+2)
10A (1.2%+2)
AC Current
400A/4000uA/40mA/400mA (1.5%+2)
10A (2.0%+2)
Resistance
400/4k/40k/400k/4M (0.8%+1)
40M (1.0%+2)
Capacitance
40nF/400nF/4F/40F/400F/4000F (4.0%+5)
Frequency
10Hz~10MHz (0.5%+2)
Duty cycle
1%~99% (2.0%+2)
Temperature(C)
-20C~1000C (2.0%+2)
Display 4000 Counts
Auto and manual range
Relative Measurement
Ma/Min Value hold
Data hold
Non-Contact Voltage Detector(NCV)
Diode test
Transistor
Continuity
Back light
Power supply 9V6F22 Battery
Safety Rating CE CAT.III1000V CAT.IV600V RoHS
Package Includes:
Digital Multimeters * 1
Pen * 1
Battery * 1
Instructions * 1
