Specifications
Range
Best Accuracy
Model
UT106
DC Voltage (V)
200mV/2V/20V/200V/1000V
(0.5%+2)
AC Voltage (V)
200V/750V
(0.8%+5)
DC Current (A)
200mA/10A
(0.8%+5)
Resistance ()
200/2k/20k/200k/2M/20M
(0.8%+5)
Frequency (Hz)
2kHz
(2%+5)
Temperature (C)
-40C 1000C
(2%+8)
Features
Display Count
2000
Manual Range
Diode
Continuity Buzzer
Low Battery Indication
Data Hold
Input Protection
Input Impedance for DCV
Around 10M
Dwell
4CYL/6CYL/8CYL
(3%+5)
Tach
4CYL/6CYL/8CYL
(3%+5)
General Characteristic
Power
9V Battery6F22)
LCD Size
60mm 54 mm
Product Color
Red and Grey
Product Net Weight
351g(Including Holster)
Product Size
179mm 88mm 39mm
Standard Accessories
Battery, Test LeadHolsterPoint Contact Temperature Probe
Standard Individual Packing
Gift Bo, English Manual
Standard Quantity Per Carton
40 PCs
Standard Carton Measurement
645mm×450mm×340mm (0.0987 CBM Per Standard Carton)
Standard Carton Gross Weight
24.6 Kg
1 Multimeter
2 Test Lead
1 Temperature probe
1 English manual
