Click on the image to view the original image
- Brand Name:
- MasTech
- Model Number:
- Clamp Meter
- Display Type:
- Digital Only
- Measuring Current Range:
- 40A/400A
- Measuring Voltage Range:
- 4V/40V/400V
- Measuring Resistance Range:
- 400/4k/40k/400k/4M
- Measuring Capacitance Range:
- 40nF/400nF/4uF/40uF/400uF/4000uF
- Measuring Inductance Range:
- --
- Operating Temperature:
- 0 to 40 Celsius Degree
- Dimensions:
- 20.8 * 7.8 * 3.5cm
- Weight:
- 238g
- DIY Supplies:
- Electrical
- Supply Ability:
- 999999 Piece/Pieces per Year
- Port
- Shenzhen
Digital Clamp Multimeter AC Voltage Current Tongs Resistance Capacitance Frequency Diode and Continuity Tester Diagnostic-tool
Features:
Perform measurements of AC/DC voltage and current, resistance, capacitance, frequency, duty cycle, diode and continuity test.
Measuring frequency, AC/DC current and duty cycle by clamp.
LCD with backlight & bar graph and clamp lighting bulb.
Relative value measurement and auto range function.
Provided with one excellent cloth bag for conveniently-carrying.
Data holding, to hold the readings while taking measurement.
Maximum and minimum value measuring and holding.
Automatic indication of functions and unit symbols.
Auto power off and low battery indication.
Full overload protection and dual insulation protection.
Over-molding rubber case, shake-proof, skid-proof and good touch-feeling.
Specifications:
| General specifications: | |||
| Max. V between terminals & earth: | 1000V DC or 750V rms AC | ||
| Operating temperature: | 0 to 40 Celsius Degree (32 Fahrenheit to 104 Fahrenheit) | ||
| Storage temperature: | -10 to 50 Celsius Degree (10 Fahrenheit to 122 Fahrenheit) | ||
| Operating altitude: | Max. 2000 meters (7000 ft.) | ||
| Max. diameter for conductor: | Diameter 26mm | ||
| Max. displayed value: | 4000 digits | ||
| Auto polarity indication: | "-" for negative polarity. | ||
| Over-range indication: | "0L" or "-0L" | ||
| Converter rate: | 3 times/sec; Bar graph: 30 times/sec | ||
| Auto power off time: | 15 minute | ||
| Power supply: | 3 * 1.5V AAA battery (not included) | ||
| Multimeter size: | 20.8 * 7.8 * 3.5cm / 8.2 * 3.1 * 1.4in | ||
| Multimeter weight: | 238g / 8.4oz | ||
| Package size: | 23 * 10.5 * 6cm / 9.1 * 4.1 * 2.4in | ||
| Package weight: | 469g / 16.5oz | ||
| Measurement specifications (accuracy): | |||
| AC Current | 40A/400A | 2.0% | |
| DC Current | 40A/400A | 2.0% | |
| DC Voltage | 400mV | 1.0% | |
| 4V/40V/400V | 0.7% | ||
| 1000V | 0.8% | ||
| AC Voltage | 4V/40V/400V | 0.8% | |
| 750V | 1.0% | ||
| Frequency | By A range (current clamp) | 10Hz/1kHz/>1kHz | 1.5% |
| By ACV range | 10Hz/1kHz/10kHz | 1.5% | |
| >10kHz | Take it only as reference | ||
| By Hz/DUTY range | 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz | 0.5% | |
| Resistance | 400/4k/40k/400k/4M | 0.8% | |
| 40M | 1.2% | ||
| Capacitance | 40nF/400nF/4uF/40uF/400uF/4000uF | 4.0% | |
Package including:
1 * Digital Multimeter
2 * Test Lead
1 * Instruction Manual
