- Model Number:
- Electricity Meter
- Measuring Current Range:
- 1.5(6)A 5(20)A 10(40)An 20(80)An 30(100)An
- Measuring Voltage Range:
- AC 380V/AC 220V/ AC 100V
- Accuracy Class:
- Active Grade: 0.5 Reactive Grade: 1.0
- Operating Temperature:
- --
- Dimensions:
- 126 * 91 * 74mm
- DIY Supplies:
- Electrical
- Supply Ability:
- 999999 Piece/Pieces per Year
- Port
- Shenzhen
| | |||||||||
LCD Din Rail Three Phase Electricity Meter 50/60Hz Power Meter Current/Voltage Wattmeter Adjustable Hour Measurer Watt Meter
The energy meter has advantages of small size, high precision, good EMC, easy installation, etc. It meets the related requirement of electronic power meter in the GB/T17215, GB/T17883 and DL/T614 standards. It"s widely used in building, shopping mall, exhibition center, schools, airports, ports and factories, etc.
Features:
High precision and performance, good EMC, easy installation.
Three-phase four quadrant energy measurement, active/reactive power pulse output.
The current and voltage can be adjustable, frequency is 50/60Hz.
LCD display the time, date, KWH clearly, clock, rate period parameters can be set.
GHTS300E model can also display power parameters, such current, voltage, power factor, etc. (GHTS300 model can not).
With RS485 communication function(only GHTS300E model).
For miniaturization structure, can be installed in the terminal power distribution box.
Applicable for building, shopping mall, exhibition center, schools, airports, ports and factories, etc.
Specifications:
| Item | Parameters | |||
| Model (Optional) | GHTS300 | GHTS300E | ||
| Electric Energy Precision Grade | Active Grade: 0.5, Reactive Grade: 1.0 | |||
| Display Mode | LCD Screen Display | |||
| Signal Input | Measurement Network | Three-phase Four-wire/Three-phase Three-wire | ||
| Voltage | Rated Voltage | AC 380V/AC 220V/ AC 100V | ||
| Excess Load | 1.2 Times the Rated Value(Continuous), 2 Times Rating / 1 Second | |||
| Power Consumption | <1VA(Each Phase) | |||
| Impedence | >500k | |||
| Current | Specifications | 1.5(6)A, 5(20)A, 10(40)A, 20(80)A, 30(100)A | ||
| Excess Load | <0.4VA(Each Phase) | |||
| Impedence | <2m | |||
| Reference Frequency | 50Hz or 60Hz | |||
| Electric Energy | Four Quadrant Power Measurement | |||
| Operation Voltage | Normal Operation Voltage Range: 0.9~1.1Un | |||
| Power Consumption | <5VA | |||
| Function Modules | Electric Energy Pulse | Pulse Width: 80ms20ms Photo Isolator, Collector Open Output | ||
| Communication Interface | No | RS485, Modbus-RTU Protocol | ||
| Temperature Range | Normal Working Temperature: -10~55C, Limit Working Temperature: -20~65C | |||
| Relative Humidity | <93%(NO Condensation) | |||
| Storage Environment | -20~85C, Relative Humidity 93% | |||
| Security | Insulation | Signal, Output Terminal of the Shell Resistance>1000M | ||
| Resist Pressure | Input and Output>2kV | |||
| Installation Mode | The 35mm Standard Installation Guide | |||
| Item Size | 126 * 91 * 74mm / 4.96 * 3.6 * 2.9in | |||
| Item Weight | 645g / 22.75oz | |||
| Package Size | 17 * 14 * 10cm / 6.7 * 5.51 * 3.94in | |||
| Package Weight | 661g / 23.35oz | |||
Package List:
1 * Three Phase Energy Meter
