50mA-100A High Quality Oscilloscopes Sonde 100KHz AC / DC Current Probe for Oscilloscope Oscilloscope Accessories
This cost-effective current probe is very practical to measure Ac and DC. It has two measurement ranges to select, better fit your needs. It is also very easy to be operated and connected to oscilloscope.
Features:
It is a cost-effective current probe that can measure AC and DC at the same time.
It has two measurement range: 50mA-10A and 1A-100A to select.
Have a green indicator light and a red overload light with the inside 9V battery.
With BNC output connector, it can easily connect to instruments like oscilloscope etc.
Usually be used in the measurement of power frequency, motor driver, power supply and avionic device.
Specifications:
Measurable Current Range: 50mA-10A Peak / 1A-100A Peak
Sensitivity: 100mV/A / 10mV/A
Range of Frequency(-3db): DC-100KHZ
Load Impedance: 1M & 100pF
Insertion Impedance: 0.01
Switching Rate: 0.3V/S / 20mV/s
Working Voltage: Maximum 600Vrms
Common Mode Voltage(CMV): Maximum 600Vrms
Overload Indicator: When the red light on, it shows that the current is over the range.
Item Weight: 289.5g / 10.22oz
Package Size: 26.5 * 22 * 7.8cm / 10.43 * 8.66 * 3.07in
Package Weight: 664g/ 23.47oz
Package List:
1 * Current Probe
