Click on the image to view the original image
Overview
Quick Details
- Applicable Industries:
- Hotels, Manufacturing Plant, Farms, Restaurant, Home Use, Retail, Construction works , Energy & Mining
- Condition:
- New
- Stroke:
- 4 Stroke
- Cylinder:
- Single Cylinder
- Cold Style:
- Air-cooled
- Start:
- Electric start
- Place of Origin:
- Jiangsu, China
- Brand Name:
- Hi-earns
- Dimension(L*W*H):
- 520X490X570mm
- Weight:
- 50kg
- Certification:
- CE/ISO9001
- Warranty:
- One year
- After-sales Service Provided:
- Engineers available to service machinery overseas
- Color:
- Yellow/Green/White/Green/Red/Orange/Blue
- Air filter:
- Oil bath
- Noise:
- Low level
- Fuel tank:
- Best quality
- Fuel pump:
- Best quality
- Displacement:
- 498cc
- Engine speed:
- 3000/3600rpm
- Starting system:
- Electric start
- Fuel tank capacity:
- 5.5L
- Shaft types:
- Spline shaft
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 52X49X57 cm
- Single gross weight:
- 50.0 kg
- Package Type:
- Carton with plastic film and plywood pallets
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 10 11 - 50 >50 Est. Time(days) 7 15 To be negotiated
Related Products
Air-cooled single cylinder diesel engine 192FDE
| Model | HR170F | HR178F | HR186FA | HR188FA | HR192FD | |||||
| Type | Single-cylinder,vertical,4-stroke air-cooled diesel engine | |||||||||
| Combustion System | Direct Injection | |||||||||
| HP | 4 | 6 | 10 | 12 | 13 | |||||
| Bore×Stroke (mm) | 70×55 | 78×62 | 86×72 | 88×75 | 92×75 | |||||
| Displacement capacity (cc) | 211 | 296 | 418 | 438 | 498 | |||||
| Speed (rpm) | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 |
| Max.output (kw) | 2.8 | 3 | 4.1 | 4.4 | 6.5 | 7.1 | 7.5 | 8 | 8.5 | 9 |
| Rated output (kw) | 2.5 | 2.8 | 3.7 | 4 | 5.9 | 6.5 | 7 | 7.5 | 8 | 8.5 |
| Fuel | o# or-10# light diesel oil | |||||||||
| Fuel oil tank volume (L) | 2.5 | 3.5 | 5.5 | 5.5 | 5.5 | |||||
| Lubricatiom oil volume (L) | 0.75 | 1.1 | 1.65 | 1.65 | 1.65 | |||||
Fuel oil consumption rate (g/kw.h) | 295 | 295 | 280 | 280 | 280 | |||||
| Starting system | Recoil or Electric | |||||||||
| PTO rotation direction | It is clockwise as viewing from the flywheel end | |||||||||
| Dimension (mm) | 420×390×470 | 490×490×520 | 520x490x570 | |||||||
| Net weight (kg) | 26 | 33 | 44 | 45 | 48 | |||||
| 20FT | 300 | 176 | ||||||||
| 40HQ | 725 | 480 | 384 | |||||||
Product Description
Field of Application
♦ Our products are widely used in various fields, such as generators,water pumps, rotavator,concrete cutter,plate compactor,high pressure washer
